  • Undercarriage
    Zahn Tool Carrier
    Undercarriage

    Power unit's exclusive traction-assist feature provides extra drawbar on demand, enabling the operator to push more, pull more and traverse soft ground with minimal tire slippage.

  • Hydraulic System



    Hydraulic System








    Auxiliary: gear pump





    Flow rate
    12 gpm
    46 l/min



    Pressure
    3,000 psi
    207 bar



    Ground drive: hydrostat





    Flow rate
    19.3 gpm
    73 l/min



    Pressure
    3,500 psi
    241 bar

  • Tires/Pressure



    Tires/Pressure








    18 x 9.5-8, 2 ply, bar lug
    12 psi
    82.7 kPa



    The assembly mass
    22 lb
    1.9 L



    Urethane filled 18 x 9.5-8, 2 ply, bar lug
    N/A
    29.1 L



    The assembly mass
    36 lb
    32.2 L



    Urethane filled 20 x 10-8, ply, bar lug
    N/A




    The assembly mass
    49 lb
    22.23 kg



    18 x 8.5-8, 2 ply, turt
    22 psi
    151.7 kPa



    The assembly mass
    20 in
    9.07 kg

  • Productivity
    Zahn Tool Carrier
    Productivity

    The high-lift-arm tool carrier's 73-inch (1.85-m) hinge pin height provides the flexibility to perform an extensive range of tasks.

    4-bar linkage on bucket curl increases the high-lift-arm's rollback and dump angles so it can move materials more efficiently.

    The high-lift-arm's optional hydraulic self-leveling kit—an exclusive feature in this class—ensures that the attachment is level, so work can be more accurate and efficient.

    Kickstand provides quick and easy attachment to and removal from the power unit, increasing productivity.

    Standard mini skid steer-type attachment plate (optional with low-lift model) provides maximum versatility by enabling the tool carrier to accept more than 40 quick-change attachments.

  • Battery



    Battery








    SAE reserve capacity rating
    32 min




    SAE cold crank rating @ 0°F (-18°C)
    200 amps










    Specifications are general and subject to change without notice. If exact measurements are required, equipment should be weighed and measured. Due to selected options, delivered equipment may not necessarily match that shown.



  • Superior Support
    Zahn Tool Carrier
    Superior Support

    Your Ditch Witch equipment is backed by a worldwide network of dealers you can count on for unmatched commitment to your success. From genuine Ditch Witch parts to factory-trained service to expert advice, your Ditch Witch dealer has it all for you.

  • Fluid Capacities



    Fluid Capacities








    Fuel tank
    9 gal
    34.06 L



    Engine oil, w/filter
    2 qt
    1.9 L



    Hydraulic reservoir
    7.7 gal
    29.1 L



    Total hydraulic system volume
    8.5 gal
    32.2 L

  • Power



    Power








    Engine
    Kohler® CH750S




    Fuel
    Gasoline




    Cooling medium
    Air




    Number of cylinders
    2




    Displacement
    45.6 in3
    747 cm3



    Bore
    3.3 in
    83 mm



    Stroke
    2.7 in
    69 mm



    Manufacturer's power rating
    30 hp
    22.4 kW



    Rated speed
    3,600 rpm


  • Operation



    Operation








    Ground drive speed, forward/reverse





    Low
    3.5 mph
    5.6 km/h



    High
    5 mph
    8 km/h

  • Power Train



    Power Train








    Parking brake
    Mechanical, hand operated




    Service
    Ground drive speed/direction control brakes machine hydraulically when moved to neutral position


  • Operator's Station
    Zahn Tool Carrier
    Operator's Station

    Standard cruise control, which locks in operating speeds, reduces operator fatigue and increases productivity.

    Soft-touch, color-coded, ergonomic controls are easy to grip, easy to learn and provide smooth, easy operation.

    Convenient cargo tray is large enough to store a water bottle, work gloves, cell phone, or assorted tools.

  • Dimensions



    Dimensions

    U.S
    Metric





    Mobile length
    70 in
    1.78 m



    Wheelbase
    34.2 in
    869 mm



    Tractor back to rear axle
    26.8 in
    681 mm



    Rear axle to attachment mounting
    19.2 in
    488 mm



    Attachment mounting to front axle
    15 in
    381 mm



    Mobile height
    53.5 in
    1.36 m



    Ground clearance
    5.3 in
    135 mm



    Platform height
    10.7 in
    272 mm



    Width
    36 in
    914 mm



    Angle of departure
    25°




    Mass
    1,290 lb
    585 kg



    Vehicle clearance circle (SAE) wall to wall





    Right turn, 18 x 9.5-8 tires
    11.3 ft
    3.44 m



    Left turn, 18 x 9.5-8 tires
    10.5 ft
    3.2 m

  • Power
    Zahn Tool Carrier
    Power

    11-gallon (41.6 L) fuel tank enables the operator to work all day without having to refuel; the tank's molded-in sight glass allows the operator to keep an eye on fuel consumption.
